Thalamic nuclei in frontotemporal dementia: Mediodorsal nucleus involvement is universal but pulvinar atrophy is unique to C9orf72
Dementia Research Centre, Department of Neurodegenerative Disease, UCL Queen Square Institute of Neurology, University College London, London, UK
Centre for Medical Image Computing, Department of Medical Physics and Biomedical Engineering, University College London, London, UK
Martinos Center for Biomedical Imaging, Massachusetts General Hospital and Harvard Medical School, Boston, Massachusetts, USA
Computer Science and Artificial Intelligence Laboratory (CSAIL), Massachusetts Institute of Technology, Boston, Massachusetts, USA
Abstract
Thalamic atrophy is a common feature across all forms of FTD but little is known about specific nuclei involvement. We aimed to investigate in vivo atrophy of the thalamic nuclei across the FTD spectrum. A cohort of 402 FTD patients (age: mean(SD) 64.3(8.2) years; disease duration: 4.8(2.8) years) was compared with 104 age‐matched controls (age: 62.5(10.4) years), using an automated segmentation of T1‐weighted MRIs to extract volumes of 14 thalamic nuclei. Stratification was performed by clinical diagnosis (180 behavioural variant FTD (bvFTD), 85 semantic variant primary progressive aphasia (svPPA), 114 nonfluent variant PPA (nfvPPA), 15 PPA not otherwise specified (PPA‐NOS), and 8 with associated motor neurone disease (FTD‐MND), genetic diagnosis (27 MAPT, 28 C9orf72, 18 GRN), and pathological confirmation (37 tauopathy, 38 TDP‐43opathy, 4 FUSopathy). The mediodorsal nucleus (MD) was the only nucleus affected in all FTD subgroups (16–33% smaller than controls). The laterodorsal nucleus was also particularly affected in genetic cases (28–38%), TDP‐43 type A (47%), tau‐CBD (44%), and FTD‐MND (53%). The pulvinar was affected only in the C9orf72 group (16%). Both the lateral and medial geniculate nuclei were also affected in the genetic cases (10–20%), particularly the LGN in C9orf72 expansion carriers. Use of individual thalamic nuclei volumes provided higher accuracy in discriminating between FTD groups than the whole thalamic volume. The MD is the only structure affected across all FTD groups. Differential involvement of the thalamic nuclei among FTD forms is seen, with a unique pattern of atrophy in the pulvinar in C9orf72 expansion carriers.
Untitled section
Keywords: frontotemporal dementia, magnetic resonance imaging, thalamic nuclei
Article notes
Untitled section
Received 2019 Mar 5; Revised 2019 Oct 9; Accepted 2019 Oct 18; Collection date 2020 Mar.
1.INTRODUCTION
The thalamus is the relay station of the brain, with so many different connections that it is virtually connected to all other brain regions. It is composed of several nuclei, each of them with specific connections and functional specialization (Table 1) (Behrens et al., 2003; Hale et al., 2015; Herrero et al., 2002; Kim et al., 2013; Lambert et al., 2017; Morel, 2007; Schmahmann, 2003; Zhang et al., 2008, 2010).
| Nuclei | Structural grouping | Functional grouping | Connections | Functions |
|---|---|---|---|---|
| AV | Anterior | Limbic | Entorhinal cortex, hippocampus (subiculum), amygdala, mammillary body, insula, frontal and temporal pole, anterior cingulate, retrosplenial cortex, orbitofrontal and medial prefrontal cortices | Learning and memory, spatial navigation, emotion, drive, motivation, anomia |
| LD | Lateral | Limbic | Mammillary body, cingulate, retrosplenial cortex, hippocampus (subiculum), entorhinal cortex, orbitofrontal and medial prefrontal cortices, amygdala | Limbic (learning and memory, emotional experience and expression, drive, motivation) |
| LP | Lateral | Associative | Somatosensory cortex, posterior parietal cortex, posterior cingulate, amygdala, hippocampus, medial and dorsolateral extrastriate cortex, medial parahippocampal cortex | Higher‐order somatosensory and visual–spatial integration (e.g., goal‐directed reaching, conceptual and analytical thinking) |
| VA | Ventral | Motor/limbic | Motor, premotor and supplementary motor cortex, prefrontal cortex, amygdala, accumbens, anterior cingulate, posterior parietal cortex | Complex behaviours, motor programming, limbic (learning and memory, emotional experience and expression, drive, motivation) |
| VLa | Ventral | Motor | Primary motor and premotor cortex, cerebellum (dentate), insula, frontal operculum, brainstem, ventral mesencephalon, pallidum | Motor |
| VLp | Ventral | Motor | Primary motor and premotor cortex | Motor, articulation and language, encoding and retrieval of verbal and nonverbal information |
| VPL | Ventral | Specific sensory | Somatosensory (superior frontal gyrus, insula, brainstem) | Somatosensory |
| VM | Ventral | Motor | Visual and motor cortex | Motor |
| Intralaminar | Intralaminar | Intralaminar | Motor cortex, striatum, basal ganglia (putamen), prefrontal cortex, brainstem, spinal cord, cerebellum [predominantly to subcortical instead of cortical structures] | Sensorimotor, limbic, cognitive; attention, arousal, consciousness, memory, autonomic drive, motivation, affective components of pain, sending attention‐specific sensory information to the striatum for conditional responses |
| Midline | Medial | Associative | Amygdala, orbital, medial, and dorsal prefrontal cortex, brainstem, spinal cord, cerebellum, periaqueductal grey | Anterograde and recognition memory, cognition, habituation, olfaction, vegetative and endocrine circadian activities, autonomic drive, sending attention‐specific sensory information to the striatum for conditional responses, processing motivational‐affective components of nociceptive information |
| MD | Medial | Associative/limbic | Temporal, dorsolateral and dorsomedial prefrontal, paralimbic regions (medial and orbital prefrontal cortex), amygdala, basal forebrain, olfactory and entorhinal cortex, motor and premotor cortex, anterior cingulate | Limbic, working memory, emotional regulation, behavior (inhibition, mood, perseveration), executive functions, vertical gaze (oculomotor control) |
| LGN | Posterior | Specific sensory | Occipital, parietal cortex ‐ primary visual cortex | Relay in the visual system |
| MGN | Posterior | Specific sensory | Temporal cortex ‐ primary auditory cortex | Relay in the auditory system |
| Pulvinar | Posterior | Associative/limbic | Prefrontal, posterior parietal, temporal, occipital and parietal cortex, hippocampus, amygdala, frontal operculum, anterior cingulate, insula, parahippocampal cortex, superior colliculi | Hallucination, visual attention, language, intramodality integration of somatosensory and visual information, pain appreciation, limbic, affective and psychotic symptoms |
Thalamic atrophy is a common feature across all clinical, genetic, and pathological forms of frontotemporal dementia (FTD) (Bocchetta et al., 2018; Cardenas et al., 2007; Chow et al., 2008; Garibotto et al., 2011; Hornberger et al., 2012; Rohrer et al., 2015). FTD is a heterogeneous neurodegenerative disorder, with clinical symptoms spanning from behavioural changes to language and motor deficits. The main genetic causes are mutations in microtubule‐associated protein tau (MAPT), progranulin (GRN), and chromosome 9 open reading frame 72 (C9orf72) (Rohrer & Warren, 2011). The neuropathological abnormalities found in the brain in FTD fall into three main groups depending on the abnormal protein found in inclusions: tau, TDP‐43, and FUS (Lashley, Rohrer, Mead, & Revesz, 2015; Mackenzie & Neumann, 2016).
Given the extensive heterogeneity across the FTD spectrum, it is likely that the nuclei of the thalamus are differentially involved in the various forms of FTD and that some of the symptoms are related to the function of the nuclei affected. However, to date, no study has methodically looked at the specific thalamic nuclei in the FTD spectrum, with prior investigations focused on volumetry of the whole thalamus.
Due to recent advances in segmentation methods, it is now possible to measure individual thalamic nuclei in vivo on structural magnetic resonance (MR) scans (Iglesias et al., 2018). We therefore aimed to investigate the specific patterns of atrophy in the thalamic nuclei in a large cohort of FTD patients, to determine which nuclei are impaired across the different clinical, genetic, and pathological forms of FTD.
2.METHODS
We reviewed the UCL Dementia Research Centre FTD MRI database to identify 402 patients with a volumetric T1‐weighted MR scan passing standard quality control protocols and with a diagnosis of behavioural variant FTD (bvFTD) (Rascovsky et al., 2011), semantic variant primary progressive aphasia (svPPA), nonfluent primary progressive aphasia (nfvPPA) (Gorno‐Tempini et al., 2011), a primary progressive aphasia not otherwise specified (PPA‐NOS) (Harris et al., 2013), or FTD with associated motor neurone disease (FTD‐MND) (Table 2). One hundred‐four cognitively normal subjects, with a similar age to the patients and with a usable T1‐weighted MRI, were identified as controls. The study was approved by the local ethics committee and written informed consent was obtained from all participants.
| Groups | n | Gender, male | Age at scan (years) | Disease duration (years) | |
|---|---|---|---|---|---|
| Controls | 104 | 44% | 62.5 (10.4) | — | |
| Clinical (n = 402) | FTD‐MND | 8 | 63% | 66.9 (4.3) | 5.3 (2.9) |
| bvFTD | 180 | 68% | 62.3 (8.0) | 5.2 (3.2) | |
| nfvPPA | 114 | 46% | 67.5 (8.7) | 4.4 (2.5) | |
| PPA‐NOS | 15 | 67% | 64.2 (6.1) | 3.3 (1.7) | |
| svPPA | 85 | 56% | 63.9 (7.2) | 4.8 (2.5) | |
| Genetica (n = 73) | C9orf72 | 28 | 68% | 62.8 (5.9) | 5.5 (3.3) |
| GRN | 18 | 56% | 62.0 (6.3) | 3.1 (2.6) | |
| MAPT | 27 | 63% | 55.9 (7.5) | 5.7 (3.2) | |
| Pathologicala (n = 79) | TDP‐43 type A | 15 | 60% | 62.1 (5.8) | 3.3 (1.7) |
| TDP‐43 type B | 3 | 67% | 57.1 (7.7) | 4.8 (2.7) | |
| TDP‐43 type C | 20 | 65% | 65.3 (7.3) | 4.7 (2.8) | |
| FTDP‐17 | 7 | 71% | 51.3 (5.8) | 5.2 (3.1) | |
| tau‐Pick's | 17 | 76% | 59.7 (4.2) | 4.4 (2.2) | |
| tau‐PSP | 4 | 100% | 76.9 (7.3) | 5.1 (3.9) | |
| tau‐CBD | 9 | 78% | 61.8 (9.1) | 4.5 (0.9) | |
| FUS | 4 | 75% | 45.7 (11.7) | 3.0 (1.8) | |
Seventy‐four patients had mutations in one of the FTD‐linked genes: 27 MAPT, 18 GRN, and 28 C9orf72 carriers as well as one with a dual mutation in GRN/C9orf72, who was excluded from the individual group genetic analyses. For 81 patients, post‐mortem confirmation of the underlying neuropathology was available: FUS (n = 4), TDP‐43 type A (n = 15), TDP‐43 type B (n = 3), TDP‐43 type C (n = 20); tau with Pick's disease (n = 17), with PSP (n = 4), with CBD (n = 9), and due to FTDP‐17 (n = 7). We excluded from the pathological analysis 2 patients with tau‐GGT1 due to the small numbers. There was an overlap of 21 cases between the genetic groups and the pathological groups: 5 GRN had TDP‐43 type A, 6 C9orf72 had TDP‐43 type A and 2 had TDP‐43 type B, 7 MAPT had FTDP‐17, and the patient with the dual GRN/C9orf72 mutation had TDP‐43 type A.
Sociodemographic and clinical data are reported in Table 2. The mean age for the whole FTD group was 64.3 (SD 8.2) years with an average disease duration of 4.8 (2.8) years. There was no significant difference in age between FTD and controls (p = .067, t‐test), or for scanner type (p = .804, Chi square test), but there were more males in the FTD group than in the control group (59% vs. 44%, p = .006, Chi square test). Across the different clinical, genetic and pathological diagnoses, there was no difference for scanner type (p = .190, p = .615, and p = .053, Chi square test). There was a slightly significant difference in disease duration for the genetic (p = .018) and clinical groups (p = .042), but not for the pathological group (p = .084, ANOVA).
T1‐weighted MRIs were acquired from 1992 to 2018 with scanners from three different manufacturers: 231 on 1.5 T Signa MRI scanner (GE Medical systems, Milwaukee, WI, TR = 12 ms, TI = 650 ms, TE = 5 ms, acquisition matrix = 256 × 256, spatial resolution = 1.5 mm), 210 on 3 T Trio MRI scanner (Siemens, Erlangen, Germany, TR = 2,200 ms, TI = 900 ms, TE = 2.9 ms, acquisition matrix = 256 × 256, spatial resolution = 1.1 mm), and 65 on 3 T Prisma MRI scanner (Siemens, Erlangen, Germany, TR = 2000 ms, TI = 850 ms, TE = 2.93 ms, acquisition matrix = 256 × 256, spatial resolution = 1.1 mm).
Volumetric MRI scans were first bias field corrected and whole‐brain parcellated using the geodesic information flow (GIF) algorithm (Cardoso et al., 2015), which is based on atlas propagation and label fusion. Volumes of the whole thalamus and of its nuclei were subsequently segmented using a customised version of the module described in Iglesias et al., 2018, to accept the GIF parcellation as input for it. Based on anatomical subdivision, we combined the 52 original thalamic nuclei, and focused the analysis on the following 14 regions: anteroventral (AV), laterodorsal (LD), lateral posterior (LP), ventral anterior (VA), ventral lateral anterior (VLa), ventral lateral posterior (VLp), ventral posterolateral (VPL), ventromedial (VM), intralaminar, midline, mediodorsal (MD), lateral geniculate (LGN), medial geniculate (MGN) and pulvinar (Table 1 and Figure S1).
Left and right volumes were summed and expressed as a percentage of the total intracranial volumes (TIV), computed with SPM12 v6470 (Statistical Parametric Mapping, Wellcome Trust Centre for Neuroimaging, London, UK) running under Matlab R2014b (Math Works, Natick, MA) (Malone et al., 2015). All segmentations were visually checked for quality.
Statistical analyses were performed on thalamic volumes in SPSS software (SPSS Inc., Chicago, IL) v22.0, between control and FTD groups, using an ANOVA test adjusting for scanner type, TIV, gender, and age. Results were corrected for multiple comparisons (Bonferroni's correction) at p < .0035 (p = .05 divided by the 14 thalamic nuclei).
We performed a stepwise discriminant analysis between pairs of genetic, pathological, and clinical FTD subgroups for the thalamic nuclei and a second discriminant analysis for the whole thalamus.
3.RESULTS
Stratifying by genetics, the three groups showed significantly smaller thalamic nuclei than controls, except for VM for the GRN group and the pulvinar for both the GRN and MAPT groups. The pulvinar was only significantly smaller in C9orf72 than controls (16% difference in volume, p < .0005 ANOVA) (Table 3 and Figure 1A). The MD and LD nuclei were particularly affected in all groups (21–32% and 28–38%, p < .0005), followed by AV (17–24%, p < .0005), midline nuclei (17–26%, p < .0005), and LP (15–23%, p < .0005). Both the LGN and MGN were also affected (p < .002), with the LGN smaller in the C9orf72 group (20%) than the other groups (11%).
| n | AV | LD | LP | VA | VLa | VLp | VPL | VM | Intralaminar | Midline | MD | LGN | MGN | Pulvinar | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Genetic diagnosis | ||||||||||||||||
| Controls | 104 | Mean | 0.017 | 0.003 | 0.015 | 0.054 | 0.079 | 0.103 | 0.109 | 0.003 | 0.051 | 0.002 | 0.126 | 0.021 | 0.016 | 0.025 |
| SD | 0.002 | 0.001 | 0.002 | 0.004 | 0.006 | 0.008 | 0.011 | 0.000 | 0.004 | 0.000 | 0.015 | 0.003 | 0.002 | 0.004 | ||
| C9orf72 | 28 | Mean | 0.013 | 0.002 | 0.011 | 0.047 | 0.069 | 0.090 | 0.097 | 0.002 | 0.045 | 0.002 | 0.085 | 0.017 | 0.014 | 0.021 |
| SD | 0.003 | 0.001 | 0.003 | 0.005 | 0.006 | 0.007 | 0.010 | 0.000 | 0.004 | 0.000 | 0.017 | 0.003 | 0.002 | 0.004 | ||
| GRN | 18 | Mean | 0.013 | 0.002 | 0.012 | 0.047 | 0.071 | 0.094 | 0.100 | 0.002 | 0.045 | 0.002 | 0.090 | 0.019 | 0.014 | 0.023 |
| SD | 0.002 | 0.001 | 0.002 | 0.007 | 0.007 | 0.008 | 0.011 | 0.000 | 0.004 | 0.000 | 0.019 | 0.003 | 0.002 | 0.004 | ||
| MAPT | 27 | Mean | 0.014 | 0.002 | 0.013 | 0.050 | 0.073 | 0.096 | 0.102 | 0.002 | 0.046 | 0.002 | 0.099 | 0.019 | 0.014 | 0.025 |
| SD | 0.003 | 0.001 | 0.002 | 0.005 | 0.006 | 0.009 | 0.012 | 0.000 | 0.005 | 0.000 | 0.019 | 0.004 | 0.002 | 0.003 | ||
| Control | C9orf72 | P‐value | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 |
| % | 24 | 34 | 23 | 13 | 12 | 12 | 11 | 15 | 13 | 22 | 32 | 20 | 12 | 16 | ||
| GRN | p‐value | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | .003 | .023 | <.0005 | <.0005 | <.0005 | .002 | <.0005 | .038 | |
| % | 22 | 38 | 20 | 14 | 10 | 9 | 8 | 8 | 12 | 26 | 28 | 11 | 13 | 8 | ||
| MAPT | p‐value | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | .001 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | .804 | |
| % | 17 | 28 | 15 | 7 | 7 | 7 | 7 | 8 | 9 | 17 | 21 | 11 | 10 | 0 | ||
| Pathological diagnosis | ||||||||||||||||
| TDP‐43 type A | 15 | Mean | 0.012 | 0.002 | 0.010 | 0.046 | 0.071 | 0.093 | 0.103 | 0.002 | 0.045 | 0.002 | 0.084 | 0.018 | 0.015 | 0.022 |
| SD | 0.002 | 0.001 | 0.003 | 0.006 | 0.006 | 0.007 | 0.009 | 0.000 | 0.005 | 0.000 | 0.021 | 0.002 | 0.002 | 0.003 | ||
| TDP‐43 type B | 3 | Mean | 0.014 | 0.003 | 0.013 | 0.048 | 0.069 | 0.092 | 0.102 | 0.002 | 0.048 | 0.002 | 0.100 | 0.015 | 0.014 | 0.024 |
| SD | 0.002 | 0.001 | 0.002 | 0.003 | 0.004 | 0.007 | 0.011 | 0.000 | 0.006 | 0.000 | 0.025 | 0.003 | 0.002 | 0.002 | ||
| TDP‐43 type C | 20 | Mean | 0.015 | 0.003 | 0.014 | 0.054 | 0.077 | 0.100 | 0.105 | 0.003 | 0.050 | 0.002 | 0.105 | 0.018 | 0.015 | 0.026 |
| SD | 0.003 | 0.001 | 0.003 | 0.006 | 0.008 | 0.010 | 0.010 | 0.000 | 0.004 | 0.000 | 0.019 | 0.003 | 0.002 | 0.003 | ||
| FTDP‐17 | 7 | Mean | 0.014 | 0.002 | 0.012 | 0.050 | 0.071 | 0.092 | 0.096 | 0.002 | 0.047 | 0.002 | 0.088 | 0.016 | 0.013 | 0.025 |
| SD | 0.003 | 0.001 | 0.002 | 0.004 | 0.005 | 0.007 | 0.010 | 0.000 | 0.003 | 0.000 | 0.010 | 0.003 | 0.001 | 0.004 | ||
| tau‐Pick's | 17 | Mean | 0.014 | 0.002 | 0.013 | 0.049 | 0.072 | 0.096 | 0.104 | 0.003 | 0.049 | 0.002 | 0.089 | 0.021 | 0.014 | 0.027 |
| SD | 0.004 | 0.001 | 0.003 | 0.007 | 0.008 | 0.010 | 0.008 | 0.000 | 0.005 | 0.000 | 0.014 | 0.002 | 0.002 | 0.003 | ||
| tau‐PSP | 4 | Mean | 0.013 | 0.002 | 0.011 | 0.044 | 0.064 | 0.083 | 0.091 | 0.002 | 0.040 | 0.002 | 0.087 | 0.016 | 0.013 | 0.026 |
| SD | 0.001 | 0.001 | 0.001 | 0.003 | 0.007 | 0.009 | 0.006 | 0.000 | 0.002 | 0.000 | 0.015 | 0.002 | 0.002 | 0.006 | ||
| tau‐CBD | 9 | Mean | 0.012 | 0.002 | 0.011 | 0.044 | 0.067 | 0.090 | 0.105 | 0.003 | 0.046 | 0.002 | 0.088 | 0.020 | 0.015 | 0.026 |
| SD | 0.003 | 0.001 | 0.002 | 0.004 | 0.006 | 0.007 | 0.006 | 0.000 | 0.004 | 0.000 | 0.012 | 0.004 | 0.002 | 0.004 | ||
| FUS | 4 | Mean | 0.014 | 0.003 | 0.013 | 0.050 | 0.074 | 0.098 | 0.106 | 0.003 | 0.049 | 0.002 | 0.093 | 0.021 | 0.014 | 0.028 |
| SD | 0.002 | 0.001 | 0.003 | 0.008 | 0.009 | 0.011 | 0.013 | 0.000 | 0.005 | 0.001 | 0.025 | 0.004 | 0.003 | 0.004 | ||
| Controls | TDP‐43 type A | p‐value | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | .012 | .065 | <.0005 | <.0005 | <.0005 | .003 | .013 | .004 |
| % | 30 | 47 | 31 | 14 | 10 | 9 | 6 | 8 | 11 | 30 | 33 | 13 | 8 | 14 | ||
| TDP‐43 type B | p‐value | .177 | .589 | .362 | .017 | .003 | .009 | .028 | .057 | .076 | .234 | <.0005 | .002 | .019 | .999 | |
| % | 14 | −3 | 10 | 11 | 12 | 11 | 6 | 8 | 6 | 4 | 20 | 28 | 11 | 4 | ||
| TDP‐43 type C | p‐value | .184 | .286 | .332 | .738 | .608 | .319 | .029 | .142 | .246 | .071 | <.0005 | .023 | .1 | .106 | |
| % | 9 | 19 | 8 | 1 | 2 | 3 | 4 | 4 | 3 | 9 | 16 | 13 | 4 | −3 | ||
| FTDP‐17 | p‐value | .011 | .043 | .001 | .023 | .004 | .001 | <.0005 | .003 | .006 | <.0005 | <.0005 | <.0005 | <.0005 | .57 | |
| % | 19 | 31 | 22 | 8 | 9 | 11 | 12 | 12 | 9 | 17 | 30 | 22 | 15 | 0 | ||
| tau‐Pick's | p‐value | .002 | .01 | .001 | <.0005 | <.0005 | .002 | .003 | .081 | .019 | <.0005 | <.0005 | .482 | <.0005 | .024 | |
| % | 15 | 25 | 15 | 10 | 8 | 7 | 5 | 4 | 4 | 17 | 29 | 0 | 9 | −6 | ||
| tau‐PSP | p‐value | .076 | .436 | .032 | .001 | <.0005 | <.0005 | .005 | .015 | <.0005 | .004 | <.0005 | .095 | .015 | .401 | |
| % | 20 | 28 | 23 | 19 | 19 | 19 | 17 | 15 | 22 | 30 | 31 | 23 | 20 | −2 | ||
| tau‐CBD | p‐value | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | .297 | .603 | .002 | <.0005 | <.0005 | .784 | .403 | .358 | |
| % | 28 | 44 | 29 | 18 | 14 | 12 | 4 | 4 | 11 | 30 | 30 | 6 | 6 | −2 | ||
| FUS | p‐value | .058 | .956 | .232 | .048 | .094 | .162 | .261 | .606 | .395 | .016 | <.0005 | .936 | .137 | .045 | |
| % | 17 | 3 | 10 | 8 | 6 | 5 | 3 | 4 | 4 | 13 | 26 | 0 | 8 | −12 | ||
| Clinical diagnosis | ||||||||||||||||
| FTD‐MND | 8 | Mean | 0.012 | 0.002 | 0.009 | 0.046 | 0.068 | 0.088 | 0.099 | 0.002 | 0.044 | 0.002 | 0.084 | 0.018 | 0.014 | 0.022 |
| SD | 0.002 | 0.001 | 0.002 | 0.006 | 0.007 | 0.009 | 0.010 | 0.000 | 0.004 | 0.000 | 0.011 | 0.003 | 0.001 | 0.006 | ||
| bvFTD | 180 | Mean | 0.014 | 0.002 | 0.012 | 0.048 | 0.071 | 0.093 | 0.100 | 0.002 | 0.047 | 0.002 | 0.094 | 0.019 | 0.014 | 0.024 |
| SD | 0.003 | 0.001 | 0.003 | 0.006 | 0.007 | 0.009 | 0.011 | 0.000 | 0.005 | 0.000 | 0.017 | 0.003 | 0.002 | 0.004 | ||
| nfvPPA | 114 | Mean | 0.014 | 0.002 | 0.012 | 0.049 | 0.072 | 0.094 | 0.103 | 0.002 | 0.046 | 0.002 | 0.097 | 0.019 | 0.015 | 0.025 |
| SD | 0.003 | 0.001 | 0.003 | 0.006 | 0.007 | 0.009 | 0.010 | 0.000 | 0.005 | 0.000 | 0.016 | 0.003 | 0.002 | 0.004 | ||
| PPA‐NOS | 15 | Mean | 0.015 | 0.002 | 0.013 | 0.051 | 0.075 | 0.098 | 0.103 | 0.002 | 0.048 | 0.002 | 0.103 | 0.020 | 0.015 | 0.025 |
| SD | 0.003 | 0.001 | 0.002 | 0.007 | 0.007 | 0.008 | 0.013 | 0.000 | 0.004 | 0.000 | 0.021 | 0.003 | 0.002 | 0.004 | ||
| svPPA | 85 | Mean | 0.015 | 0.003 | 0.013 | 0.053 | 0.076 | 0.099 | 0.105 | 0.003 | 0.049 | 0.002 | 0.105 | 0.019 | 0.015 | 0.027 |
| SD | 0.003 | 0.001 | 0.003 | 0.005 | 0.007 | 0.009 | 0.011 | 0.000 | 0.005 | 0.000 | 0.018 | 0.003 | 0.002 | 0.003 | ||
| Controls | FTD‐MND | p‐value | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | .004 | .051 | <.0005 | <.0005 | <.0005 | .031 | .01 | .085 |
| % | 31 | 53 | 37 | 15 | 13 | 14 | 9 | 8 | 15 | 35 | 33 | 15 | 11 | 11 | ||
| bvFTD | p‐value | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | .099 | |
| % | 17 | 28 | 18 | 12 | 10 | 9 | 9 | 8 | 9 | 22 | 25 | 11 | 11 | 4 | ||
| nfvPPA | p‐value | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | <.0005 | .001 | <.0005 | <.0005 | <.0005 | .014 | .001 | .747 | |
| % | 16 | 31 | 18 | 10 | 9 | 8 | 6 | 8 | 10 | 22 | 23 | 8 | 7 | 0 | ||
| PPA‐NOS | p‐value | .008 | <.0005 | .011 | .137 | .25 | .219 | .132 | .266 | .062 | .004 | <.0005 | .333 | .691 | .492 | |
| % | 13 | 31 | 14 | 6 | 5 | 5 | 6 | 8 | 7 | 17 | 18 | 7 | 4 | −1 | ||
| svPPA | p‐value | <.0005 | <.0005 | <.0005 | .086 | .054 | .009 | .006 | .026 | .001 | <.0005 | <.0005 | <.0005 | 0.011 | .001 | |
| % | 9 | 22 | 11 | 3 | 3 | 4 | 4 | 4 | 4 | 9 | 17 | 10 | 4 | −7 | ||
Stratifying by pathology, MD was the only nucleus affected in all subgroups (29–33% and 20% in TDP‐43 type B, p < .0005) and the only nucleus affected in FUS (26%, p < .0005) and TDP‐43 type C (16%, p < .0005) (Table 3 and Figure 1B). The LD was also particularly affected in TDP‐43 type A (47%, p < .0005) and tau‐CBD (44%, p < .0005). These two groups had the most nuclei affected followed by tau‐Pick's disease, with sparing of VPL, VM, and the pulvinar in each of these groups.
Stratifying by clinical diagnosis, the MD was affected in all subgroups, with FTD‐MND being the most affected (33%), and svPPA and PPA‐NOS the least (17–18%, p < .0005). The LD was also affected in all subgroups, especially in FTD‐MND (53%, p < .0005). The pulvinar was spared in all groups. FTD‐MND was the group with the smallest volumes overall, with PPA‐NOS the least affected group (Table 3 and Figure 1C).
Comparisons between the disease groups for each of the three analyses are reported in the Table S1.
We also repeated the above analyses in a purely sporadic cohort, excluding the 21 genetic cases. The results for the clinical and pathological subgroups showed a similar pattern of nuclei involvement despite a reduction in the sample sizes and therefore the statistical power. The sporadic FTD‐MND group still showed the highest volumetric differences from controls in the LP, MD, and midline nuclei (Table S2), and the sporadic TDP‐43 type A cases mainly showed volume differences in the MD, midline, LD, and LP (Table S3).
The volumetric comparisons between the FTD groups are reported in the Table S3.
Results of the discriminant analysis are shown in Table 4. Overall, the accuracy to correctly classify the groups was higher when using one or a combination of thalamic nuclei, than the whole thalamus. Among the genetic groups, the best classification was between MAPT and C9orf72 using the pulvinar volumes, which correctly classified 70% of the MAPT carriers and 79% C9orf72 (p < .0005). Among the pathological groups, 100% correct classification was obtained between FUS and tau‐PSP using VA, VLp, and intralaminar nuclei (p < .0005), between tau‐Pick's and tau‐PSP using LD, intralaminar, and LGN (p < .0005), between tau‐PSP and TDP‐43 type C using AV, VM, and intralaminar (p < .0005), and between TDP‐43 type A and TDP‐43 type B using LD, VLa, and midline nuclei (p = .001). Among clinical groups, classification accuracy was no better than using the whole thalamus (Table 4).
| Thalamic nuclei | Whole thalamus | ||||||
|---|---|---|---|---|---|---|---|
| p‐Value | % CC | Predictors | Correlation | p‐Value | % CC | ||
| Genetic diagnosis | |||||||
| MAPT | GRN | .046 | 89/50 | VA | 1 | .955 | |
| C9orf72 | <.0005 | 70/79 | Pulvinar | 1 | .002 | 56/75 | |
| GRN | C9orf72 | .042 | 33/82 | LGN | 1 | .943 | |
| Pathological diagnosis | |||||||
| FUS | tau‐CBD | .021 | 50/89 | LD | 1 | .900 | |
| FTDP‐17 | .068 | 50/100 | LGN | 1 | .776 | ||
| tau‐Pick's | NA | NA | .992 | ||||
| tau‐PSP | <.0005 | 100/100 | VA/VLp/Intralaminar | (−18.985/8.539/12.227) | .067 | 75/100 | |
| TDP‐43 type A | .006 | 50/93 | Pulvinar | 1 | .848 | ||
| TDP‐43 type B | .076 | 100/0 | LGN | 1 | .927 | ||
| TDP‐43 type C | NA | NA | .997 | ||||
| tau‐CBD | FTDP‐17 | .006 | 100/71 | Midline | 1 | .976 | |
| tau‐Pick's | .02 | 33/88 | Midline/MD | (1.445/−1.022) | .945 | ||
| tau‐PSP | .004 | 89/75 | VPL | 1 | .074 | 89/25 | |
| TDP‐43 type A | .006 | 67/87 | VLa/Pulvinar | (−0.857/1.075) | .964 | ||
| TDP‐43 type B | .003 | 100/33 | Midline | 1 | .998 | ||
| TDP‐43 type C | <.0005 | 56/90 | Midline | 1 | .047 | 11/85 | |
| FTDP‐17 | tau‐Pick's | .001 | 71/94 | Intralaminar/LGN | (0.634/1.063) | .880 | |
| tau‐PSP | .003 | 86/100 | Intralaminar/LGN | (1.378/0.975) | .038 | 100/75 | |
| TDP‐43 type A | .017 | 57/87 | VPL/Pulvinar | (−0.795/0.887) | .994 | ||
| TDP‐43 type B | NA | NA | .956 | ||||
| TDP‐43 type C | .030 | 14/95 | MD | 1 | .018 | 0/85 | |
| tau‐Pick's | tau‐PSP | <.0005 | 100/100 | LD/Intralaminar/LGN | (−1.15/1.537/1.05) | .013 | 100/25 |
| TDP‐43 type A | <.0005 | 88/73 | Pulvinar | 1 | .025 | 65/67 | |
| TDP‐43 type B | .001 | 94/67 | LGN | 1 | .979 | ||
| TDP‐43 type C | <.0005 | 77/75 | Intralaminar/MD/LGN | (0.694/−0.977/0.806) | .964 | ||
| tau‐PSP | TDP‐43 type A | .019 | 50/100 | VPL | 1 | .937 | |
| TDP‐43 type B | .052 | 100/67 | Intralaminar | 1 | .628 | ||
| TDP‐43 type C | <.0005 | 100/100 | AV/VM/Intralaminar | (−1.33/−1.093/2.51) | .004 | 25/95 | |
| TDP‐43 type A | TDP‐43 type B | .001 | 100/100 | LD/VLa/Midline | (0.945/−1.418/1.097) | .971 | |
| TDP‐43 type C | <.0005 | 73/85 | Midline/Pulvinar | (0.738/0.597) | .002 | 73/80 | |
| TDP‐43 type B | TDP‐43 type C | NA | NA | .939 | |||
| Clinical diagnosis | |||||||
| bvFTD | nfvPPA | <.0005 | 84/36 | AV/VM/Intralaminar/MGN | (0.807/1.091/−1.622/0.667) | .045 | 95/3 |
| PPA‐NOS | .031 | 100/0 | MGN | 1 | .982 | ||
| svPPA | <.0005 | 88/41 | VA/Pulvinar | (0.782/0.433) | <.0005 | 92/25 | |
| FTD‐MND | .002 | 100/0 | LP | 1 | .981 | ||
| nfvPPA | PPA‐NOS | NA | NA | .991 | |||
| svPPA | <.0005 | 76/47 | VA | 1 | <.0005 | 84/41 | |
| FTD‐MND | .004 | 100/0 | LP | 1 | .007 | 100/0 | |
| PPA‐NOS | svPPA | NA | NA | .993 | |||
| FTD‐MND | .002 | 87/63 | Midline | 1 | .006 | 73/50 | |
| svPPA | FTD‐MND | <.0005 | 98/50 | LP/Midline/Pulvinar | (0.482/0.452/0.543) | <.0005 | 98/13 |
4.CONCLUSIONS
In a large cohort of FTD patients we have shown that the MD is the only thalamic nucleus affected across all FTD groups. There is differential thalamic involvement among the FTD forms, with unique involvement of the pulvinar in C9orf72 expansions carriers. Involvement of thalamic nuclei was more in the genetic forms of FTD than the sporadic forms with only MD involvement (and no other nuclei) in TDP‐43 type C and FUSopathies.
The MD is connected to several brain regions typically affected in FTD (Table 1), particularly prefrontal, temporal, and limbic areas that play a role in executive function as well as emotional and behavioural regulation. Prior small pathological studies have shown that the MD is specifically affected by chronic degenerative changes (e.g., neuronal depletion, gliosis, and astrocytosis) in FTD (in a single case with bvFTD (Radanovic et al., 2003) and in a group of ubiquitin‐positive cases (Mackenzie et al., 2006)).
The LD nucleus is also significantly smaller across the genetic and clinical groups: this is another nucleus with a key role in the limbic system, and is strongly connected to regions commonly affected across the FTD spectrum (Schmahmann, 2003) (Table 1).
Our findings of unique pulvinar atrophy in C9orf72 expansion carriers are in line with the literature on imaging (Lee et al., 2014; Lee et al., 2016) and with pathological studies (Vatsavayai et al., 2016; Yang, Halliday, Hodges, & Tan, 2017) that have previously shown pulvinar involvement in C9orf72 carriers: one histological study showed that almost all the neurons in the pulvinar had inclusions containing TDP‐43 and dipeptide repeat proteins (Vatsavayai et al., 2016). The pulvinar is a key region for limbic functions and intramodality integration of sensory information (Schmahmann, 2003) (Table 1). Atrophy in this nucleus can lead to altered processing of pain, hallucinations, and both affective and psychotic symptoms. This is in line with frequently reported clinical symptoms in C9orf72 carriers that tend not to be found in other forms of FTD (Ducharme, Bajestan, Dickerson, & Voon, 2017; Fletcher et al., 2015). We also found that the LGN was particularly affected in C9orf72, an area previously linked to visual hallucinations which are a common feature of this genetic group (Ducharme et al., 2017; Kertesz et al., 2013).
We showed that by using the volume of a single thalamic nucleus or a combination of them, the accuracy in distinguishing between pairs of FTD subgroups was considerably higher than the accuracy in using the whole thalamus alone, especially for the genetic and pathological groups. This suggests that measuring individual thalamic nuclei rather than the whole thalamus may prove to be a better diagnostic biomarker for FTD, potentially as part of a wider set of volumetric measures.
Limitations of this study include the use of different scanners (three manufacturers, two different magnetic fields: 1.5 T and 3 T) with slightly different MRI sequence types. Even if we correct for scanner type and gender in the statistical model, we cannot completely remove some of the intrinsic heterogeneity due to these variables. However the algorithm operates at an internal resolution of 0.33 mm, which might compensate for the different native resolutions of the scans. Moreover, due to its unsupervised model for image intensities and to its Bayesian nature, this segmentation method is agnostic to the contrast of the MR images, and it is thus robust to the contrast changes between the scans acquired on different scanners. Whilst we used an automated method to extract the thalamic nuclei volumes, which is not as accurate as manual segmentation on dedicated MRIs or on brain tissue post‐mortem, we combined the 52 regions in the initial segmentation into 14 nuclei in order to decrease the effect of a less reliable delineation on T1‐weighted MRI. Furthermore, manual segmentation is extremely time‐consuming and labour‐intensive in such a large cohort. As there is no reliable measure of disease severity for FTD, and there is heterogeneity across its forms in the rate of disease progression, another limitation is the difficulty in characterising the level of disease severity between groups.
Further studies with longitudinal data and both diffusion‐weighted and functional MRI are needed to understand the differential involvement of thalamic nuclei over the course of the disease, and the changes in thalamic connectivity to other regions of the brain. Particularly important will be the investigation of presymptomatic mutation carriers in whom the earliest disease changes can be seen. However, this study has already highlighted both common and unique features of thalamic nuclei involvement across the FTD spectrum, adding to our understanding of the heterogeneity of this neurodegenerative illness.
CONFLICT OF INTEREST
J.D.R. has been on a Medical Advisory Board for Wave Life Sciences and Ionis Pharmaceuticals.
Supporting information
ACKNOWLEDGMENTS
The Dementia Research Centre is supported by Alzheimer's Research UK, Brain Research Trust, and The Wolfson Foundation. This work was supported by the NIHR Queen Square Dementia Biomedical Research Unit and the NIHR UCL/H Biomedical Research Centre, the MRC UK GENFI grant (MR/M023664/1) and the Alzheimer's Society (AS‐PG‐16‐007). J.D.R. is supported by an MRC Clinician Scientist Fellowship (MR/M008525/1) and has received funding from the NIHR Rare Disease Translational Research Collaboration (BRC149/NS/MH). J.D.W. receives grant support from the Alzheimer's Society, Alzheimer's Research UK and by the NIHR UCL/UCLH Biomedical Research Centre. J.E.I. is supported by the European Research Council (Starting Grant 677697, project BUNGEE‐TOOLS).
Untitled section
Bocchetta M, Iglesias JE, Neason M, Cash DM, Warren JD, Rohrer JD. Thalamic nuclei in frontotemporal dementia: Mediodorsal nucleus involvement is universal but pulvinar atrophy is unique to C9orf72 . Hum Brain Mapp. 2020;41:1006–1016. 10.1002/hbm.24856
Untitled section
Footnote Group
DATA AVAILABILITY STATEMENT
The data that support the findings of this study are not publicly available due to ethical restrictions.
REFERENCES
Untitled section
References
- Behrens, T. E. , Johansen‐Berg, H. , Woolrich, M. W. , Smith, S. M. , Wheeler‐Kingshott, C. A. , Boulby, P. A. , … Matthews, P. M. (2003). Non‐invasive mapping of connections between human thalamus and cortex using diffusion imaging. Nature Neuroscience, 6(7), 750–757.
- Bocchetta, M. , Gordon, E. , Cardoso, M. J. , Modat, M. , Ourselin, S. , Warren, J. D. , & Rohrer, J. D. (2018). Thalamic atrophy in frontotemporal dementia—Not just a C9orf72 problem. Neuroimage Clinical, 18, 675–681.
- Cardenas, V. A. , Boxer, A. L. , Chao, L. L. , Gorno‐Tempini, M. L. , Miller, B. L. , Weiner, M. W. , & Studholme, C. (2007). Deformation‐based morphometry reveals brain atrophy in frontotemporal dementia. Archives of Neurology, 64, 873–877.
- Cardoso, M. J. , Modat, M. , Wolz, R. , Melbourne, A. , Cash, D. , Rueckert, D. , & Ourselin, S. (2015). Geodesic information flows: Spatially‐variant graphs and their application to segmentation and fusion. IEEE Transactions on Medical Imaging, 34, 1976–1988. 10.1109/TMI.2015.2418298
- Chow, T. W. , Izenberg, A. , Binns, M. A. , Freedman, M. , Stuss, D. T. , Scott, C. J. , … Black, S. E. (2008). Magnetic resonance imaging in frontotemporal dementia shows subcortical atrophy. Dementia Geriatric Cognitive Disorders, 26, 79–88.
- Ducharme, S. , Bajestan, S. , Dickerson, B. C. , & Voon, V. (2017). Psychiatric presentations of C9orf72 mutation: What are the diagnostic implications for clinicians? Journal of Neuropsychiatry and Clinical Neurosciences, 29(3), 195–205.
- Fletcher PD, Downey LE, Golden HL, Clark CN, Slattery CF, Paterson RW, Rohrer JD, Schott JM, Rossor MN, Warren JD. (2015) Pain and temperature processing in dementia: A clinical and neuroanatomical analysis. Brain 138(Pt 11):3360–3372.
- Garibotto, V. , Borroni, B. , Agosti, C. , Premi, E. , Alberici, A. , Eickhoff, S. B. , … Padovani, A. (2011). Subcortical and deep cortical atrophy in frontotemporal lobar degeneration. Neurobiology of Aging, 32, 875–884.
- Gorno‐Tempini, M. L. , Hillis, A. E. , Weintraub, S. , Kertesz, A. , Mendez, M. , Cappa, S. F. , … Grossman, M. (2011). Classification of primary progressive aphasia and its variants. Neurology, 76(11), 1006–1014.
- Hale, J. R. , Mayhew, S. D. , Mullinger, K. J. , Wilson, R. S. , Arvanitis, T. N. , Francis, S. T. , & Bagshaw, A. P. (2015). Comparison of functional thalamic segmentation from seed‐based analysis and ICA. NeuroImage, 114, 448–465.
- Harris, J. M. , Gall, C. , Thompson, J. C. , Richardson, A. M. , Neary, D. , du Plessis, D. , … Jones, M. (2013). Classification and pathology of primary progressive aphasia. Neurology, 81(21), 1832–1839.
- Herrero, M. T. , Barcia, C. , & Navarro, J. M. (2002). Functional anatomy of thalamus and basal ganglia. Child's Nervous System, 18(8), 386–404.
- Hornberger M, Wong S, Tan R, Irish M, Piguet O, Kril J, Hodges JR, Halliday G. (2012) In vivo and post‐mortem memory circuit integrity in frontotemporal dementia and Alzheimer's disease. Brain 135(Pt 10):3015–3025.
- Iglesias, J. E. , Insausti, R. , Lerma‐Usabiaga, G. , Bocchetta, M. , Van Leemput, K. , Greve, D. N. , … Paz‐Alonso, P. M. (2018). A probabilistic atlas of the human thalamic nuclei combining ex vivo MRI and histology. NeuroImage, 183, 314–326.
- Kertesz, A. , Ang, L. C. , Jesso, S. , MacKinley, J. , Baker, M. , Brown, P. , … Finger, E. C. (2013). Psychosis and hallucinations in frontotemporal dementia with the C9ORF72 mutation: A detailed clinical cohort. Cognitive and Behavioral Neurology, 26(3), 146–154.
- Kim, D. J. , Park, B. , & Park, H. J. (2013). Functional connectivity‐based identification of subdivisions of the basal ganglia and thalamus using multilevel independent component analysis of resting state fMRI. Human Brain Mapping, 34(6), 1371–1385.
- Lashley, T. , Rohrer, J. D. , Mead, S. , & Revesz, T. (2015). Review: An update on clinical, genetic and pathological aspects of frontotemporal lobar degenerations. Neuropathology and Applied Neurobiology, 41(7), 858–881.
- Lambert, C. , Simon, H. , Colman, J. , & Barrick, T. R. (2017). Defining thalamic nuclei and topographic connectivity gradients in vivo. NeuroImage, 158, 466–479.
- Lee SE, Khazenzon AM, Trujillo AJ, Guo CC, Yokoyama JS, Sha SJ, Takada LT, Karydas AM, Block NR, Coppola G, Pribadi M, Geschwind DH, Rademakers R, Fong JC, Weiner MW, Boxer AL, Kramer JH, Rosen HJ, Miller BL, Seeley WW. (2014) Altered network connectivity in frontotemporal dementia with C9orf72 hexanucleotide repeat expansion. Brain 137(Pt 11):3047–3060.
- Lee, S. E. , Sias, A. C. , Mandelli, M. L. , Brown, J. A. , Brown, A. B. , Khazenzon, A. M. , … Seeley, W. W. (2016). Network degeneration and dysfunction in presymptomatic C9ORF72 expansion carriers. NeuroImage: Clinical, 10(14), 286–297.
- Mackenzie IR, Baker M, West G, Woulfe J, Qadi N, Gass J, Cannon A, Adamson J, Feldman H, Lindholm C, Melquist S, Pettman R, Sadovnick AD, Dwosh E, Whiteheart SW, Hutton M, Pickering‐Brown SM. (2006) A family with tau‐negative frontotemporal dementia and neuronal intranuclear inclusions linked to chromosome 17. Brain 129(Pt 4):853–867.
- Mackenzie, I. R. , & Neumann, M. (2016). Molecular neuropathology of frontotemporal dementia: Insights into disease mechanisms from postmortem studies. Journal of Neurochemistry, 138 Suppl 1, 54–70.
- Malone, I. B. , Leung, K. K. , Clegg, S. , Barnes, J. , Whitwell, J. L. , Ashburner, J. , … Ridgway, G. R. (2015). Accurate automatic estimation of total intracranial volume: A nuisance variable with less nuisance. NeuroImage, 104, 366–372.
- Morel, A. (2007). Stereotactic atlas of the human thalamus and basal ganglia. New York: Informa Healthcare.
- Radanovic, M. , Rosemberg, S. , Adas, R. , Miranda, S. C. , Caramelli, P. , Caixeta, L. , & Nitrini, R. (2003). Frontotemporal dementia with severe thalamic involvement: A clinical and neuropathological study. Arquivos de Neuro‐Psiquiatria, 61(4), 930–935.
- Rascovsky, K. , Hodges, J. R. , Knopman, D. , Mendez, M. F. , Kramer, J. H. , Neuhaus, J. , … Miller, B. L. (2011). Sensitivity of revised diagnostic criteria for the behavioural variant of frontotemporal dementia. Brain, 134, 2456–2477.
- Rohrer, J. D. , & Warren, J. D. (2011). Phenotypic signatures of genetic frontotemporal dementia. Current Opinion in Neurology, 24, 542–549.
- Rohrer, J. D. , Nicholas, J. M. , Cash, D. M. , van Swieten, J. , Dopper, E. , Jiskoot, L. , … Rossor, M. N. (2015). Presymptomatic cognitive and neuroanatomical changes in genetic frontotemporal dementia in the genetic frontotemporal dementia initiative (GENFI) study: A cross‐sectional analysis. Lancet Neurology, 14(3), 253–262.
- Schmahmann, J. D. (2003). Vascular syndromes of the thalamus. Stroke, 34(9), 2264–2278.
- Vatsavayai SC, Yoon SJ, Gardner RC, Gendron TF, Vargas JN, Trujillo A, Pribadi M, Phillips JJ, Gaus SE, Hixson JD, Garcia PA, Rabinovici GD, Coppola G, Geschwind DH, Petrucelli L, Miller BL, Seeley WW. (2016) Timing and significance of pathological features in C9orf72 expansion‐associated frontotemporal dementia. Brain 139(Pt 12):3202–3216.
- Yang, Y. , Halliday, G. M. , Hodges, J. R. , & Tan, R. H. (2017). von Economo neuron density and thalamus volumes in behavioral deficits in Frontotemporal dementia cases with and without a C9ORF72 repeat expansion. Journal of Alzheimer's Disease, 58(3), 701–709.
- Zhang, D. , Snyder, A. Z. , Fox, M. D. , Sansbury, M. W. , Shimony, J. S. , & Raichle, M. E. (2008). Intrinsic functional relations between human cerebral cortex and thalamus. Journal of Neurophysiology, 100(4), 1740–1748.
- Zhang, D. , Snyder, A. Z. , Shimony, J. S. , Fox, M. D. , & Raichle, M. E. (2010). Noninvasive functional and structural connectivity mapping of the human thalamocortical system. Cerebral Cortex, 20(5), 1187–1194.
Associated Data
Supplementary Materials
Data Availability Statement
The data that support the findings of this study are not publicly available due to ethical restrictions.
