Phytoremediation: A Novel Approach of Bast Fiber Plants (Hemp, Kenaf, Jute and Flax) for Heavy Metals Decontamination in Soil—Review
1Environmental Science Programme, Faculty of Science & Natural Resources, Universiti Malaysia Sabah, UMS Road, Kota Kinabalu 88400, Sabah, Malaysia
2Small Islands Research Center, Universiti Malaysia Sabah, UMS Road, Kota Kinabalu 88400, Sabah, Malaysia
*Correspondence: zaidazahari@ums.edu.my; Tel.: +60-13-898-8754Abstract
Heavy metal pollution in the environment is a major concern for humans as it is non-biodegradable and can have a lot of effects on the environment, humans as well as plants. At present, a solution to this problem is suggested in terms of a new, innovative and eco-friendly technology known as phytoremediation. Bast fiber plants are typically non-edible crops that have a short life cycle. It is one of the significant crops that has attracted interest for many industrial uses because of its constant fiber supply and ease of maintenance. Due to its low maintenance requirements with minimum economic investment, bast fiber plants have been widely used in phytoremediation. Nevertheless, these plants have the ability to extract metals from the soil through their deep roots, combined with their commercial prospects, making them an ideal candidate as a profit-yielding crop for phytoremediation purposes. Therefore, a comprehensive review is needed for a better understanding of the morphology and phytoremediation mechanism of four commonly bast fiber plants, such as hemp (Cannabis sativa), kenaf (Hibiscus cannabinus), jute (Corchorus olitorius) and Flax (Linum usitatissimum). This review article summarizes the existing research on the phytoremediation potential of these plants grown in different toxic pollutants such as Lead (Pb), Cadmium (Cd) and Zinc (Zn). This work also discusses several aids including natural and chemical amendments to improve phytoremediation. The role of these amendments in the bioavailability of contaminants, their uptake, translocation and bioaccumulation, as well as their effect on plant growth and development, has been highlighted in this paper. This paper helps in identifying, comparing and addressing the recent achievements of bast fiber plants for the phytoremediation of heavy metals in contaminated soil.
1. Introduction
Industrialization includes the rapid growth in manufacturing and production as well as technological changes. Growth is required for better productivity, an increase in the standard of living, growth in population, urbanization and more. The rise in urbanization is also expected to go up to 60% by 2030. However, this transformation is causing a drastic change in Earth’s ecosystem, negatively impacting the environment with air pollution, topsoil contamination, groundwater contamination and water pollution. Industrial wastes are more toxic compared to municipal wastes because of the presence of oil, grease, heavy metals, phenols, ammonia and more [1]. Emissions from mining, power plants and refineries are some of the major sources of hazardous toxic chemicals that pollute the environment.
Soil pollution is characterized as the accumulation of persistent toxic compounds, chemicals, salts, radioactive materials, or disease-causing agents, which adversely affect plant growth and animal health in soils. This pollution decreases the quality of the crop as the effect of using of pesticides and chemical fertilizers. Exposure to toxic and dangerous chemicals can increase the health risks to people living nearby and on polluted land. For example, heavy metals can enter humans’ bodies through food, water, air and bioaccumulation over a period of time [2]. This could lead to acute and chronic illness in the central nervous system and peripheral nervous system [3]. Moreover, the toxic effects of heavy metals can cause an imbalance in the ecosystem of the soil. Heavy metals in soils exist in four different forms: dissolved ions, organic complexes, exchangeable ions and precipitates [4]. These compositions are dangerous because they tend to bioaccumulate in plant tissues. Metals such as zinc (Zn), nickel (Ni), manganese (Mn), iron (Fe) and copper (Cu) do contribute their importance in plant growth and help physiological processes such as the electron transfer system in photosynthesis. Other metals such as cadmium (Cd), arsenic (As), chromium (Cr), mercury (Hg) and lead (Pb) do not carry any known biological roles in plants. However, an excessive amount of heavy metal will affect biological and biochemical processes negatively by restraining growth and lowering the chlorophyll content of the plants. For instance, a plant with high lead concentrations fastens the production of reactive oxygen species (ROS), causing lipid membrane damage that ultimately leads to damage of chlorophyll and photosynthetic processes and suppresses the overall growth of the plant [5].
Heavy metal contamination in soil has a negative impact on the environment, especially on soil quality and plant growth. Once the plant is saturated with heavy metal, the plant dies due to the interruption in photosynthesis and protein synthesis. Elimination of heavy metals is difficult as it is irreversible and remediation needs to be done. Remediation can be divided into in-situ and ex-situ remediation. In-situ remediation is a process of remediation that does not require transport of contaminated soil to off-site treatment facilities. Ex-situ remediation, on the other hand, is the remediation technique that requires excavation of contaminated soil to an off-site treatment facility [4]. This process requires additional costs. However, the treatments are controlled and accelerated and provide better results in a shorter time. Examples of in-situ remediation are surface capping, encapsulation, electro-kinetics, soil flushing, immobilization, phytoremediation and bioremediation. Examples of ex-situ remediation techniques are landfilling, soil washing, solidification and vitrification [4].
Phytoremediation is a cost-effective remediation technique with ecological benefits and high public acceptance. This method is scientifically proven for the remediation of contaminants with the only limitations being the time-consuming process and the possibility of adverse effects on living beings due to biomagnification. This limitation can be overcome using non-edible commercial plants that have rapid growth rates and are easy to maintain. With these characteristics, a bast fiber plant with various plant parts is a good option for phytoremediation. They are also used in the production of a variety of products, such as paper, textiles, wrapping materials, rope, strings, baskets and so on, which will improve the socioeconomic status of people who live in contaminated areas or who use contaminated lands for agricultural purposes. Bast fibre, also known as phloem fibre, is a type of plant fibre derived from the phloem or bast that surrounds the stem of certain dicotyledonous plants. Bast fibres plants can be obtained from either cultivated herbs such as Flax, Hemp and Ramie, or from wild plants such as linden, wisteria and mulberry. The physical properties of different bast fibers that possess a series of characteristics: (1) ability to accumulate metals preferable in the above parts, (2) tolerance to accumulated metal concentrations, (3) production of high biomass and (4) not consumable by humans and animals, making them suitable for use in phytoremediation [6,7].
It is also crucial to understand that edible plants are not appropriate for phytoremediation because they may affect the health of humans or animals once they are consumed [8]. Therefore, fiber crops are said to be the best fit for phytoremediation. This is because fiber plants involve a cycle of planting and harvesting, which help to reduce the heavy metal contamination in the soil over time, and the harvested fiber is used to manufacture biomaterials such as paper and textiles. In this case, it does not enter the food chain and affects the environment negatively, such as harming humans or animal health. Apart from that, different plants have different methods for the removal and accumulation of heavy metals (Figure 1). For example, some plants can stabilize or decrease the mobility of the pollutants in the soil through accumulation in the roots through root hairs to stop contaminants’ run-off, bulk erosion and air-borne transport [9]. Other plants may be involved in the process of plant uptake and release into the atmosphere through transpiration, which is known as phytovolatilization. Many phytoremediation processes are possible through better relationships in between plants, microbes, soil and contaminants. These different processes of phytoremediation perform different management options for a better end product to the environment [6].
This paper discusses the potential of four commonly used bast fiber plants namely Cannabis sativa (Hemp), Hibiscus cannabinus (Kenaf), Corchorus olitorius (Jute) and Linum usitatissimum (Flax) for phytoremediation of selective heavy metals, such as cadmium (Cd), lead (Pb) and zinc (Zn) from contaminated soil. The main goal of this paper is to provide references for suitable bast fiber plants for heavy metal treatment. In addition, this review summarises these plants’ ability to accumulate heavy metal elements and reveals their potential for use as phyotoaccumulators or phytostabilizers via their uptake mechanisms. This emerging technology can be improved with natural and chemical amendments that make heavy metals bioavailable and soluble.
2. Bast Fiber Plants
2.1. Morphology and Characteristics of Bast Fiber Plants (Hemp, Kenaf, Jute and Flax)
Bast fibre is a natural fibre derived from the bast environment of certain dicotyledonous angiosperm plant stems. It is made up of cellulose and hemicellulose combined with a lignin or pectin mixture. In this paper, the potential of four different fiber plants from various places in the uptake of heavy metals from contaminated soil was highlighted. The four fiber plants are Hemp (Cannabis sativa), Kenaf (Hibiscus cannabinus), Jute (Corchorus olitorius) and Flax (Linum usitatissimum) (Table 1).
Hemp is a member of the Cannabaceae plant family, and the fibre derived from this plant is one of the strongest forms of natural fibre [10]. It has the potential to be an environmentally friendly and a highly sustainable crop if it is well managed. On the other hand, Kenaf and Jute come from the same family of Malvacea. Kenaf is a non-wood fiber that can be used for reinforcement and it is the world’s third traditional crop after wood and bamboo, which originate in Asia and Africa [11]. Jute fibers are totally biodegradable as it is partially wood [12]. Flax is a member of the Linaceae family of plants, and because its exceptional qualities, Flax fibres are significant raw materials for textiles [12]. Flax and Hemp do not have much difference because they are both cellulose fibers, except that Hemp has ten chromosomes (2n = 20), whereas Flax has 15 pairs of chromosomes (2n = 30) [13]. Kenaf and Jute are woody-stemmed herbaceous dicotyledons grown in the tropics and subtropics.
2.2. Application of Bast Fiber Plants (Hemp, Kenaf, Jute and Flax)
Fiber plants are useful not only for phytoremediation but also in a variety of other fields in the world (Table 2). The bast fibre of hemp plants is used in the automotive industry and textile industry, whereas the whole plant part is used for feedstock and biofuel. Hurds are used for paper production and as a building material such as fiberglass. Hemp oil from the seeds is used in shampoos, soaps and bathing gels. The seeds are also applicable in the food industry as hemp milk and are used as a salad dressing. Technical commercial products such as oil paints, ink and coatings are also produced by these plants [18]. However, the usage of the plants is based on the quality of the hemp. On the other hand, Jute is the second most important fiber plant in the world, and it is also one of the cheapest-grown fiber plants in the tropical region. It is traditionally used to manufacture packaging materials such as sacking, ropes, twines and carpet-backing cloth. Moreover, diversified Jute is also used in the production of home textiles, composites, geotextiles, paper pulp, technical textiles, chemical products, handicrafts and fashion accessories. The woody central core is used as a rural building material for fences, fuel and for charcoal-making. In the Philippines, the leaves of Jute are used to treat headaches [19].
Kenaf also has its own uses and one of them is paper production. Kenaf paper is stronger and more resistant to yellowing compared wood paper and it requires fewer bleaching agents. Furthermore, Kenaf seeds produce edible oil, which is one of the best cooking oils. Dried Kenaf leaves are consumed as a vegetable in some countries because they contain 30% crude protein. The fruit of Kenaf helps in lowering blood pressure and the presence of vitamin C and antioxidants in Kenaf help in fighting some diseases. Kenaf will be used in new applications such as medicines, textiles, natural fiber compounds and environmental cleaning [20]. Flax is used for fruit, medications and textiles and has therefore been used for food processing. It has been of considerable significance for human civilization and growth for more than 8000 years. For many years, Flax was commonly used for the manufacture of fabrics, although nowadays, oil is the main source in production [21].
3. Advantages and Limitations of Phytoremediation
As mentioned earlier, phytoremediation is a promising method for cleaning up heavy metal-contaminated soils. Despite the numerous challenges, phytoremediation is regarded as a green remediation technology with enormous potential. The main advantages of this method are cost effectiveness, eco-friendliness and practicality compared to other mediation technologies. However, there are some limitations that need to be addressed in this process. This includes huge funds expenditure and human resources as well as favorable weather and climatic conditions for plants. The advantages and limitations of phytoremediation are described in detail in Table 4.
4. Summary
Global trends toward sustainable development have brought phytoremediation as one of the emerging technologies for the decontamination of heavy metals in soil. Bast fiber plants are very promising candidates since they show tolerance to toxic trace elements in soils, have fast-growing and yield high biomass, have low maintenance, and are well known in the industrial sector. Based on the heavy metal content results in the fiber crops studied, the following conclusions can be drawn:
- Heavy metal accumulation in bast fiber plants is clearly showed in vegetative and reproductive organs. Hemp (Cannabis sativa) is the crop that most strongly accumulates Zn followed by Kenaf (Hibiscus cannabinus), Jute (Corchorus olitorius), and Flax (Linum usitatissimum). It is notable that Jute is more tolerant and best uptake potential for Cd as compared to others crops.
- It is reported that the distribution of heavy metals Pb, Zn, and Cd is selective to roots as compared to shoot for all bast fiber plants studied.
- It is suggested that Hemp, Kenaf, and Jute are suitable species for soil remediating of heavy metals Pb and Zn. Therefore, these species can be successfully cultivated for phytoremediation purposes since their root system can remove significant amounts of heavy metals from the soil.
Institutional Review Board Statement
Not applicable.
Informed Consent Statement
Not applicable.
Data Availability Statement
Not applicable.
Conflicts of Interest
The authors declare no conflict of interest.
| Fiber Plants | Morphology | |||||
|---|---|---|---|---|---|---|
| Roots | Stems | Leaves | Flowers | Seeds | Reference | |
| Hemp (Cannabis sativa) | Root system is well developed with depth of about 1 to 1.5 m | The stems are normally hollow with diameter ranging from 5 to 25 mm. The base and top stem have different diameters. Mature plant reaches up to 5 m | The first true leaves are single leaflets; later leaves become palmate compounds. The second leaf pair consists of three leaflets per leaf, the third leaf pair has five leaflets per leaf, and so on, up to eleven leaflets per leaf | Male flowers and female flowers available. Female flowers are more compact | Hemp seeds are achenes seeds. Seeds are ellipsoid in shape, 2 to 7 mm long and 2 to 4 mm wide in diameter. Seeds vary in colour from light brown to dark green | [14] |
| Kenaf (Hibiscus cannabinus) | It has a prolific root system with a long taproot and extensive lateral roots | It mainly has unbranched stems and grows up to 4.5 m tall | Young leaves are simple and entire. Divided leaf can produce 3 to 10 entire young leaves prior to the first divided leaf | It produces large showy, light yellow, creamy coloured flowers that are bell-shaped and widely open. The flowers are solitary, short-stalked and auxiliary and are 8 to 13 cm in diameter with 5 petals, 5 sepals and numerous stamens | The seeds are normally brown with 6 mm long and 4 mm wide. The seeds of Kenaf are produced by the fruits, known as fruit capsules in 1.9 to 2.5 cm long and 1.3 and 1.9 cm in diameter with many seeds, around 20 to 26 | [15] |
| Jute (Corchorus olitorius) | It has an extensive lateral branching and deep tap root system | The height range of the Jute plant is between 2 and 4 m. The stems are about 1 to 2 cm in diameter with few branches. The colour of the stem, petiole and leaf varies. | The leaves are edible with a bitter taste. Leaves are usually 6–10 cm long and 3.5–5 cm broad | It consists of small pale-yellow flower, bracts lanceolate, 2 to 3 cm wide, sepals 3 mm long and petals are 5 mm long | Seeds are greyish- black and angled | [16] |
| Flax (Linum usitatissimum) | It has short and branched tap root that can extend to a depth, of1 m, with side branches spreading to 30 cm | It has one main stem, but two or more branches (tillers) may develop from the base when plant density is low or with high soil nitrogen levels | The leaves are normally small and lance- shaped | The flowers parts are normally in units of five and can range from a dark to a very light blue, white or pale pink | The seeds are flat, oval and pointed at one end. Normally the seeds are covered in mucilage, giving it a high shine | [17] |
| Types of Fiber Plants | Hemp (Cannabis sativa) | Kenaf (Hibiscus cannabinus) | Jute (Corchorus olitorius) | Flax (Linum usitatissimum) |
|---|---|---|---|---|
| Ranking | ||||
| 1 | China | India | India | Russia |
| 2 | Canada | China | Bangladesh | Canada |
| 3 | United States of America | Thailand | China | Kazakhstan |
| 4 | France | Brazil | Uzbekistan | China |
| 5 | Chile | Vietnam | Nepal | United States |
| 6 | North Korea | Cuba | South Sudan | India |
| 7 | Indonesia | Zimbabwe | ||
| 8 | Pakistan | Egypt | ||
| 9 | Pakistan | Vietnam | ||
| 10 | Cambodia | Bhutan | ||
| References | [22] | [23] | [24] | [25] |
| Types of Fiber Plants | Metals | Concentration (mg/kg−1) | Reference | ||
|---|---|---|---|---|---|
| Roots | Leaves | Shoots | |||
| Hemp (Cannabis sativa) | Pb | 38.2 | 16.5 | 23.5 | [33] |
| Pb | 14.6 | 2.22 | 2.07 | [36] | |
| Cd | 2.82 | 0.23 | 0.37 | [36] | |
| Cd | 1.03 | 0.55 | 0.98 | [33] | |
| Zn | 688.6 | 323.1 | 156 | [36] | |
| Zn | 66.8 | 40.0 | 54.5 | [33] | |
| Kenaf (Hibiscus cannabinus) | Pb | 2.43 | - | 8.9 | [28] |
| Pb | 329.66 | - | 867.55 | [37] | |
| Cd | 0.87 | - | 0.36 | [8] | |
| Cd | 0.25 | - | 0.14 | [38] | |
| Zn | 233.0 | - | 264.0 | [30] | |
| Zn | 114 | 65 | - | [39] | |
| Zn | 377.78 | 133.33 | - | [40] | |
| Jute (Corchorus olitorius) | Pb | 21.74 | - | - | [41] |
| Pb | 367.83 | 370.43 | - | [31] | |
| Cd | 163 | - | 48 | [31] | |
| Cd | 261.83 | 41.35 | - | [42] | |
| Zn | 148.53 | 151.42 | - | [42] | |
| Flax (Linum usitatissimum) | Pb | 104.4 | 14.5 | 30.2 | [33] |
| Pb | 310.56 | - | - | [34] | |
| Cd | 13.06 | - | - | [34] | |
| Cd | 8.69 | 1.62 | 7.27 | [33] | |
| Zn | 255.71 | - | - | [34] | |
| Zn | 211.8 | 32.6 | 62.9 | [33] | |
| Advantages | Limitations | Reference |
|---|---|---|
| It is cost-efficient | It takes longer time to achieve the results as it is a slow process | [74,75] |
| Soil properties will not be affected during the process of phytoremediation, as it is environmentally friendly | The toxins, pH and concentration of contaminants must be below the plant’s tolerance level | |
| Applicable for large, contaminated areas | Cannot be carried out in a medium with excessive concentration of contaminants suitable for shallow contamination (within the rooting zone) at non-excessive concentrations | [76] |
| Helps to reduce the possibility of soil erosion and prevent the metals in the affected area from leaching | Possibility of high toxins entering food chain because of poor management | |
| Can be used for both in situ and ex situ applications | Only suitable for shallow contamination, which means until the depth of the root | [77] |
| Has the potential to be a permanent treatment in treating a wide range of contaminants | The remediated plant biomass could be dangerous as it contains hazardous wastes |
