Successful Treatment of Pancreatic Fistula Following Surgery for Congenital Biliary Dilatation with Endoscopic Ultrasound-Guided Transduodenal Drainage
Department of Surgery, Gunma Prefecture Saiseikai Maebashi Hospital, Maebashi, Japan
Department of Gastroenterology, Gunma Prefecture Saiseikai Maebashi Hospital, Maebashi, Japan
Department of General Surgical Science, Graduate School of Medicine, Gunma University, Maebashi, Japan
Abstract
Despite improvements in surgical techniques and perioperative management, postoperative pancreatic fistula (PF) is often difficult to treat and can be fatal due to various complications without effective drainage. Here, we report a case of PF following surgery for congenital biliary dilatation (CBD) successfully managed by endoscopic ultrasound (EUS)-guided transduodenal drainage. A 55-year-old woman underwent extrahepatic bile duct resection, including the gallbladder, and biliary tract reconstruction for CBD. On the 10th postoperative day (POD), computed tomography (CT) showed fluid retention observed from the upper edge of the pancreatic head to the surface of the right lobe of the liver. First, percutaneous fine-needle aspiration was performed on the fluid retention in the lateral part of the liver on the 11th POD. The amylase level in the drainage was high (30,156 U/L), and we diagnosed it as PF. Percutaneous drainage was difficult for fluid retention on the cut surface of the pancreas; thus, drainage under EUS guidance was decided. On the 13th POD, EUS was performed, a scan of the duodenal bulb revealed fluid retention with debris inside, and approximately 20-mL fluid was aspirated (amylase: 139,200 U/L). Although the inflammatory response temporarily improved, it recurred, so we decided to perform continuous drainage. On the 21st POD, EUS was performed again; a 19-G needle was used; a 0.025-in angle-type Jagwire was advanced into the fluid retention and expanded using a 7-Fr dilator; and then, a 6-Fr endoscopic nasoabscess drain (ENAD) tube was placed. On the 29th POD, CT showed that the fluid retention on the upper edge of the head of the pancreas had shrunk to a thickness of approximately 20 mm. On the 30th POD, the patient started eating. The ENAD tube was removed on the 38th POD. The patient was discharged from the hospital on the 45th POD without any symptoms. EUS-guided transduodenal drainage is an effective treatment option for postoperative PF following surgery for CBD.
Untitled section
Keywords: Pancreatic fistula, Endoscopic ultrasound-guided transduodenal drainage, Congenital biliary duct dilation
Article notes
Untitled section
Received 2021 Oct 22; Accepted 2022 Jan 7; Collection date 2022 Jan-Apr.
Introduction
Postoperative pancreatic fistula (PF) mainly occurs due to insufficiency of suturing of the anastomotic site after pancreatectomy and leakage of pancreatic juice from the branched pancreatic duct exposed in the cross-section. Once a PF develops, it is often refractory and, without effective drainage, can be accompanied by bacterial infections, intra-abdominal abscess, sepsis, and even pseudoaneurysm formation and rupture, leading to intra-abdominal bleeding, which can be fatal [1]. Although, recently, endoscopic ultrasound (EUS)-guided transmural drainage for PF after pancreaticoduodenectomy has been reported to be useful [2], few authors have reported EUS-guided transmural drainage after surgery for congenital biliary dilatation (CBD). Here, we report a case of postoperative PF following surgery for CBD successfully managed by EUS-guided transduodenal drainage.
Case Presentation
A 55-year-old woman underwent extrahepatic bile duct resection, including the gallbladder, and biliary tract reconstruction for Todani classification type IV-A CBD (Fig. 1a, b). The reconstruction method used was hepaticojejunostomy with Roux-en-Y. The drain was placed in the foramen of Winslow, dorsal of the anastomotic site. The patient started eating foods on the 5th postoperative day (POD). No problems with the drainage were encountered, and it was removed on the 7th POD. However, the inflammatory response was prolonged after that. On the 10th POD, computed tomography (CT) showed fluid retention observed from the upper edge of the pancreatic head (the site where the bile duct was resected) to the surface of the right lobe of the liver (Fig. 2a, b). First, percutaneous fine-needle aspiration was performed on the fluid retention in the lateral part of the liver on the 11th POD. The amylase level in the drainage was high (i.e., 30,156 U/L), and we diagnosed it as PF (grade B according to the definition by the International Study Group of PF) [3]. Percutaneous drainage was difficult to perform for fluid retention on the cut surface of the pancreas, so drainage under EUS guidance was decided. On the 13th POD, EUS was performed, a scan of the duodenal bulb revealed fluid retention with debris inside (Fig. 3a), and approximately 20-mL fluid was aspirated (Fig. 3). The amylase level in the drainage was also high (139,200 U/L). On the 14th POD, magnetic resonance cholangiopancreatography was performed, and no damage to the main pancreatic duct was observed. We determined that it was a PF from the exfoliated surface of the pancreas. Although the inflammatory response temporarily improved, it recurred, so we decided to perform continuous drainage. On the 21st POD, EUS was performed again, showing that the bulb was swollen due to fluid retention in the PF. A 19-G needle was punctured; a 0.025-in angle-type Jagwire was advanced into the fluid retention (Fig. 3c) and expanded using a 7-Fr dilator; and then, a 6-Fr endoscopic nasoabscess drain (ENAD) tube was placed (Fig. 3d). Approximately 50-mL purulent drainage was observed. On the 29th POD, CT showed that the fluid retention on the upper edge of the head of the pancreas had shrunk to a thickness of approximately 20 mm (Fig. 4a). On the 30th POD, the patient started eating foods. On the 31st POD, contrast enhancement using urografin was performed from the ENAD tube. It was imaged along the shape of the pigtail loop. The tube was pulled out a little and refixed. After that, almost no drainage was observed, and inflammatory reaction also improved. On the 38th POD, the ENAD tube was removed. The patient was discharged from the hospital on the 45th POD without any symptoms (Fig. 4b).
Discussion
CBD is a combination of localized dilatation of the extrahepatic bile duct, including the common bile duct, and anomalies of the pancreaticobiliary junction. It is a congenital dysplasia causing various pathological conditions, such as impaired outflow or reflux of bile and pancreatic juice and a complication of biliary tract cancer [4, 5]. Since biliary tract cancer occurs at a high rate in the dilated bile duct and gallbladder, extrahepatic bile duct resection including the gallbladder, which is the carcinogenic origin, and biliary tract reconstruction are standard surgical procedures [6]. Moreover, carcinogenesis, pancreatitis, and pancreatic stones, among others, from the residual bile duct in the pancreas have been reported after surgery [7]. From this, excising the lower part of the common bile duct near the confluence of the pancreatic duct is necessary without sparing the intrapancreatic bile duct as much as possible [8].
Early complications after surgery for CBD include bleeding, PF, acute pancreatitis, gastrointestinal bleeding, and ileus; however, the frequency of these complications is not high. Todani et al. [9] have reported that 12 of 74 cases (16.4%) had early complications, such as suture failure, bleeding, acute pancreatitis, ileus, gastrointestinal bleeding, and PF. However, in patients with a significantly large bile duct dilation as in the patient in this case report, the risk of PF is high because the detached area from the pancreas inevitably becomes large.
PF remains one of the most notable clinical complications that are directly linked to surgery-related death. Regarding the treatment of PF, antibacterial drugs [10], nutritional support [11], somatostatin analogs [12, 13], interventional radiology [14, 15], and surgical treatment [16, 17], among others, were mentioned. Although the standard treatment has not yet been established, there seems to be no dispute that drainage is the most important. In the patient in this case report, a drain was placed in the foramen of Winslow. Recently, in drain management after pancreatic resection, removing the drain within 5 days is recommended if there is no suspicion of PF [13, 18], and even in this case, it is removed relatively early. However, it is possible that the drainage was inadequate. The drain may have been placed so that proper drainage would work for the “dent” that was hollowed out of the intrapancreatic bile duct; however, repositioning the drain is anatomically difficult.
In contrast, endoscopic drainage has been attempted for postoperative PF, and its usefulness has been reported recently [19, 20, 21]. There are two types of endoscopic drainage: trans-papillary drainage and EUS-guided transluminal drainage. Both selections consider the PF condition. Trans-papillary drainage should be prioritized for acute peripancreatic fluid collection before cyst wall formation or with main pancreatic duct stenosis, and EUS-guided transluminal drainage should be selected if this is ineffective or if there is an infectious complication [22, 23]. However, the aim of the trans-papillary drainage is to ensure the antegrade trans-papillary outflow of pancreatic juice and to reduce leakage of pancreatic juice secondarily. That is, the drainage effect of the stored liquid itself is not strong. In this case, there was no stenosis of the main pancreatic duct, which was accompanied by an infection; thus, EUS-guided transluminal drainage was selected. Furthermore, ENAD was selected as the method of continuous drainage because priority was given to being able to observe the amount of drainage and properties in real time. It is also possible to perform cleaning and contrast. Although the patient felt discomfort in the pharynx, the discomfort was alleviated using a relatively thin tube, and eating food was possible, even during indwelling.
Considering that the indication for walled-off necrosis after acute pancreatitis is 4 weeks after the onset, there is an opinion that it is better to wait 4 weeks after the operation for the EUS-guided drainage [24]. In contrast, after pancreatic resection, adhesion of serosa of surrounding organs is observed for approximately 2–3 days [25]. The PF generated at the surgical site is expected to be localized by being surrounded by the serosa of the surrounding organs that have adhered. Therefore, unlike the case of pseudopancreatic cysts occurring in acute pancreatitis, hesitating to perform drainage early may not be necessary. In this case, only EUS-guided aspiration was initially performed; however, continuous drainage may have been performed from the beginning.
The purpose of EUS-guided drainage is to reduce fluid retention, and confirming the reduction of the lesion diameter of the PF by imaging examination and observing the improvement of the patient's subjective symptoms and inflammatory reaction over time are necessary. Furthermore, some complications after drainage are serious, such as bleeding and perforation. In addition to strict follow-up, if complications appear, a prompt response, including surgical procedures, is required.
In conclusion, the risk of PF is relatively high in CBD with remarkable large bile duct dilatation, similar to the patient in this case report. Although effective drainage placement during surgery seems to be the most important, EUS-guided transduodenal drainage is an effective treatment option for PF after surgery for CBD.
Statement of Ethics
This study protocol was reviewed and approved by the Ethics Committee of Gunma Prefecture Saiseikai Maebashi Hospital, approval No. 2021-022. Written informed consent was obtained from the patient for publication of this case report and any accompanying images.
Conflict of Interest Statement
The authors declare no conflict of interest.
Funding Sources
No grant support or funding from public institutions or private enterprises was received for this case report.
Data Availability Statement
All data generated or analyzed during this study are included in this article. Further inquiries can be directed to the corresponding author.
Acknowledgment
The authors would like to thank Enago (www.enago.jp) for the English language review.
