Rescuing the Rescuer: Fractured Dormia Basket and a Second Basket Rescue Technique
Department of Gastroenterology, The Ruth and Bruce Rappaport Faculty of Medicine, Technion—Israel Institute of Technology, Haifa, Israel; Department of Gastroenterology, Rambam Health Care Campus, Haifa, Israel
Department of Gastroenterology, Rambam Health Care Campus, Haifa, Israel
Iyad Khamaysi, Department of Gastroenterology, The Ruth and Bruce Rappaport Faculty of Medicine, Technion—Israel Institute of Technology, Haifa, Israel; Department of Gastroenterology, Rambam Health Care Campus, Haifa, Israel, Phone: +972 4 777 2850, e-mail: k_iyad@rambam.health.gov.ilABSTRACT
Mechanical lithotripsy is one of the well-known rescue methods for impacted common bile duct (CBD) stones. A fractured Dormia basket with a captured stone is an unusual complication and poses a special management problem. In the past, surgical intervention was the standard method. Various nonsurgical techniques have been reported. If the impaction is at the level of the papilla, extending the sphincterotomy might be sufficient. Stent insertion, endoscopic mechanical lithotripsy, extracorporeal shock wave lithotripsy, endoscopic laser lithotripsy, and transhepatic choledochoscopic lithotripsy have all been reported. In this case, we used a second basket, which is readily available and less expensive, as a rescue technique.
How to cite this article
Khamaysi I, Hajj E. Rescuing the Rescuer: Fractured Dormia Basket and a Second Basket Rescue Technique. Euroasian J Hepato-Gastroenterol 2020;10(1):45–46.
A 71-year-old woman had an 8-week history of biliary-like abdominal pain and abnormal liver function tests. A cholecystectomy was performed 15 years before presentation.
Transabdominal ultrasound and CT of the abdomen showed only CBD dilatation (up to 12 mm).
Endoscopic ultrasound (EUS) showed a paradiverticular papilla and dilated CBD with a 12-mm floating stone (Fig. 1A).
During endoscopic retrograde cholangiopancreatography (ERCP), sphincterotomy was done and the stone was caught by a Dormia basket (Fig. 1A), but unfortunately, while retrieving the basket, it was impacted at the level of the papilla. A rescue mechanical lithotripsy was initiated. The duodenoscope was withdrawn and the Soehendra metal sheath was advanced over the exposed Dormia basket under fluoroscopic control (Fig. 1B). However, while cranking the lithotripter, the four wires of the basket were fractured leaving the stone/basket complex impacted in the distal CBD (Fig. 1B). Due to the paradiverticular position, the sphincterotomy could not be further extended, so a 12-mm-balloon sphincteroplasty was performed and a second Dormia basket was introduced. The stone/basket complex was disengaged; the stone was retrieved successfully but the fractured basket tip went proximally into the right hepatic duct. After many attempts, the fractured basket was caught (Fig. 1C) and retrieved by the second basket (Fig. 1D).
Clinically, abdominal pain and the liver tests abnormalities were resolved completely.
Mechanical lithotripsy is one of the well-known rescue methods for impacted CBD stones.1 A fractured Dormia basket with a captured stone is an unusual complication and poses a special management problem. In the past, surgical intervention was the standard method. Various nonsurgical techniques have been reported. If the impaction is at the level of the papilla, extending the sphincterotomy might be sufficient. Stent insertion, endoscopic mechanical lithotripsy, extracorporeal shock wave lithotripsy, endoscopic laser lithotripsy, and transhepatic choledochoscopic lithotripsy have all been reported.2
In this case, we used a second basket, which is readily available and less expensive, as a rescue technique.
To the best of our knowledge, only three similar cases,3,4 in which a second basket was used to retrieve the fractured basket and impacted stone, were published so far in English literature.
