Coming to Terms with a Conundrum: A Case of Primary Progressive Apraxia of Speech due to Corticobasal Degeneration?
Neurology Unit “San Gerardo” Hospital and University of Milano-Bicocca, Monza, Italy
Neurology Unit, “Niguarda” hospital, Milano, Italy
Abstract
Primary progressive apraxia of speech (PPAOS) is a progressive disorder impairing the motor speech act leaving linguistic function unattained. Although apraxia of speech frequently co-occurs with other neurodegenerative conditions, PPAOS defines a clinical syndrome where apraxia of speech is the sole or prominent symptom for much of the disease's natural history. Mounting evidence is beginning to fully define this disease as the epiphenomenon of 4-repeat (4R) tau pathology although other pathologic signatures have been reported. Indeed, PPAOS patients generally present a parkinsonian syndrome late into their natural history mostly qualifying for either corticobasal syndrome (CBS) or progressive supranuclear palsy (PSP). This is starting to be reflected in diagnostic criteria for PSP, namely, in the PSP speech and language (SL) subcategory; however, this inclusion is not reflected for CBS. Here, we present a single case of a patient with PPAOS and her clinical follow-up lasting 6 years, from the time she sought our attention to her death which occurred 8 years into the disease. PPAOS was the only and prominent symptom for most of the illness with extrapyramidal signs overtly presenting in the last months of its course. Clinical evaluation, imaging, genetic, and cerebrospinal fluid biomarkers all pointed toward an underlying CBD pathology, albeit the eventual anatomopathological confirmation was not performed. Had her clinical course been more suggestive of PSP, she would have qualified for criteria as PSP-SL. Our case therefore suggests the hypothetic need to discuss the broadening of the existing CBS criteria to encompass isolated PPAOS.
Untitled section
Keywords: Primary progressive apraxia of speech, Speech, Corticobasal syndrome
Article notes
Untitled section
Received 2021 Feb 26; Accepted 2021 May 17; Collection date 2021 May-Aug.
Introduction
Primary progressive apraxia of speech (PPAOS) is a disorder characterized mainly by a selective and slowly progressive speech production deficit, deeply affecting word articulation. Usually, at symptom onset and for a consistent period of time into the disease, there is no impairment of any other linguistic and/or nonlinguistic neuropsychological function apart from orofacial apraxia which is almost always associated [1].
PPAOS is actually considered as the expression of a focal cortical neurodegenerative syndrome [2, 3]. Nonetheless, symptoms can also constitute a familial hallmark of broader neurodegeneration [4] and coexist with primarily impaired linguistic function [5]. Perhaps, due to this particular nature, PPAOS has been named in various ways, during the past years [2, 6, 7, 8, 9]. However, the definition that is gaining most momentum is PPAOS [10] with other names being regarded as its synonyms [11]. Mounting accounts are defining a condition where speech production is the prominent, if not only, symptom of progressive neurodegeneration for a consistent period of time [12, 13, 14, 15, 16, 17, 18, 19]. However, as it inevitably occurs in neurodegeneration, pathology spreads, attaining other cerebral areas and leading to the manifestation of broader symptomatology late into the disease's natural history.
In several cases, PPAOS can be the early clinical presentation of corticobasal syndrome (CBS) or progressive supranuclear palsy (PSP) [20, 21, 22], with pathological footing being determined mostly by 4R-tau pathology [14, 15, 23, 24]. However, albeit rare, cases of PPAOS due to beta-amyloid pathology have been described [24, 25], with only one being autoptically confirmed [26]. This plausibly justifies performing a lumbar puncture to a PPAOS patient. Furthermore, cases of PPAOS have been described progressing to amyotrophic lateral sclerosis (ALS) [9, 13], some with genetic suggestion of an underlying TDP-43 pathology [27] and autoptic confirmation [28].
Although underreported, PPAOS can constitute up to around 20% of progressive higher-level language and speech disorders [29], and its chameleonic nature justifies an extensive workup for a correct pathological framing thus enabling the patient to be allocated into the right clinical trial and, where available, be eligible for symptomatic therapy. Hence, such a thorough characterization is indicated only for subspecialists or researchers working with phasic troubles in dementia or clinicians with ampler field of interests who wish to obtain diagnostic precision.
Here, we report a single patient affected by PPAOS and her follow-up lasting 4 years, from the time she sought our attention to her death which occurred 8 years into the disease. Surprisingly enough, her condition never bloomed into a fully fledged clinical syndrome during the course of her illness, with her symptoms qualifying for possible CBD only right before her death.
Case Report
The patient was a 75-year-old right-handed female former shop owner with 5 years of formal education and a negative family history for neurodegenerative disease. She had sought our attention after a 4-year history of slowly progressive impaired articulation and mild forgetfulness that sneakily emerged after mourning for a family member. All previous specialist evaluations had framed her condition as functional and reactive to her sorrow. She had a brain MRI taken at symptom onset showing diffuse and nonspecific cerebral atrophy and a carotid ultrasonography that was normal. Moreover, she presented a past history of hypertension and dyslipidemia, for which she was taking medications, and rheumatoid arthritis that was now quiescent. On admission to our ward for an initial diagnostic workup, her speech was slurred, fragmented, and presented with occasional paraphasias while neurologic examination failed to evidence further abnormalities. A brain 18F-FDG PET was taken, documenting moderate hypometabolism of precentral and postcentral gyri and temporal lobes bilaterally, although hypometabolism was more marked on the left hemisphere (Fig. 1A). After workup, she was discharged with the diagnosis of slowly progressive anarthria and mild nonamnesic cognitive impairment and was referred to our outpatient memory clinic for follow-up. Along the next years, her dysarthria slowly worsened, but no other consistent deficits emerged during repeated clinical examinations or were reported by either caregivers or the patient.
Seven years into the disease, her MRI profile was markedly asymmetrical between hemispheres with a more severe involvement of the left structures in particular involving the left parietal and temporal lobes (Fig. 2) without involving brainstem structures such as the midbrain. In addition, also a second brain 18F-FDG PET showed frontal, parietal, and temporal hypometabolism that was more marked on the left (Fig. 1B), and a DaTSCAN SPECT evidenced dopaminergic degeneration mostly involving the left putamen. Clinically, her most prominent impairment was speech production, which left her almost mute, and she also presented marked orofacial apraxia. At this stage of the disease, her muscle tone was still normal, no falls were reported either by the patient or the caregivers, and her eye movements showed no abnormalities. However, she now exhibited also a marked reduction of mental flexibility and started to unexplainably flee from home. Nonetheless, she was self-sufficient in daily life activities. Her comprehension was intact, and she could still express herself in written form although her writing was littered with marked phonemic errors mainly in the form of substitutions and omissions with slight notes of agramattism (Fig. 3). A lumbar puncture was performed with normal glucose, protein, and cells. CSF beta-amyloid was 655 pg/mL (normal values >500 pg/mL), total tau was 153 pg/mL (normal values <500), and phospho-tau was 28 pg/mL (normal values <61 pg/mL). Genetic testing was performed: GRN, C9ORF72, and TARBDP were all negative for mutations.
Her last visit at the outpatient clinic was more than 7 years into the disease, and she evidenced extinction upon double touch, notes of limb apraxia, ideomotor slowing, pronounced mental inflexibility, and perseveration. The last time she was assessed, 8 years into the disease, she was at home for she was bedridden due to marked postural instability and asymmetric limb rigidity. The patient had to be fed and helped with daily life activities. Eventually, she developed dysphagia and died of ab ingestis pneumonia.
Discussion
The condition presented by our patient appears to be consistent with PPAOS. In line with most accounts, hindrance in word articulation was the main and only symptom for a substantial part of disease duration (7 years in our case) [9, 13, 19, 27, 30, 31]. Orofacial apraxia appeared until very late into the disease, while frank language impairment failed to develop until the very end. Structural and functional imaging showed a marked posterior frontal and temporal degeneration that was preponderantly lateralized to the left side. Although most cases seem to show a prevalent frontal anterior involvement [30], others [17, 19] depose for a more posterior one, emphasizing the heterogeneous nature of this disease. Neatly, the DaTSCAN was in line with substantial evidence marking basal ganglia involvement [19, 32]. In comparison with other accounts [13, 19, 21, 22, 33], our case presented limited signs of a significant parkinsonian syndrome only very late into the disease. Indeed, the patient's clinical condition satisfied criteria for possible CBD pathology [34] (asymmetric rigidity/akinesia and cortical sensory loss) only right before her death.
In summary, we reported the natural history of a single case of PPAOS who unlike already described cases did not overtly progress into an evident parkinsonian syndrome. Furthermore, although the majority of PPAOS cases seem to be due to PSP [21, 22] and diagnostic categories for PSP now comprise a speech and language variant [35], our case, with good probability, was due to an underlying CBD, which in itself constitutes a less common phenomenon. At present, there are only 3 single case reports of PPAOS due to CBD [18, 19, 33], but CBD is also the final diagnosis in a minority of patients in published case series [13, 21, 22]. In particular, if follow-up is sufficiently long (i.e., >6 years), a Parkinson plus syndrome appears to inevitably develop supporting PPAOS as an early presentation of a Parkinson plus disorder [36]. Obviously, the lack of a pathological confirmation represents the major eventual limit to our diagnostic hypothesis, thus posing a limitation to the scientific scope of this study, for a portion of the conclusions lacks backing by pathological evidence. However, it should also be noted that due to different intrinsic variables that may be due to consent by the family, ethical issues, institutional practice, or national custom, histopathologic confirmation is difficult to obtain in tantamount occurences, marking the same aforementioned limitation for other studies in this topic as well. Finally, a minor limit is that the patient somehow could not completely satisfy criteria for probable CBD. However, evidence is pointing toward cognitive manifestations of the frontal type as preponderant in early stages of CBS (a key criterion for antemortem diagnosis of CBD) with parkinsonian signs emerging later into the disease [37], suggesting that a broadening of the existing criteria might perhaps be needed.
Indeed, although diagnostic criteria for antemortem CBD diagnosis encompass apraxia of speech, they regard it as a component of nonfluent/agrammatic primary progressive aphasia [34], which in its own terms can be misleading, for apraxia of speech proper is not a disorder of language but rather of speech. We therefore may propose a new subcategory for the in vivo diagnosis of CBD, akin to the SL category already established for PSP [35], comprising cases of early and predominant PPAOS. Further case reports and series with neuropathological confirmation will be unquestionably needed in order to establish if this interesting hypothesis could be validated.
Statement of Ethics
The research was conducted ethically in accordance with the World Medical Association Declaration of Helsinki, and the patient gave written informed consent to this publication, including to the use of the images. Due to the article type, no ethics committee approval was needed.
Conflict of Interest Statement
The authors declare that they have no conflicts of interest.
Funding Sources
The authors did not receive any funding.
